Crux VRFMB-78A Rear- & Front-view Integration for 2012 – 2016 Mercedes-Benz w/ NTG4.5 Systems

The CRUX VRFMB-78A is a Rear-vision and Front-vision integration interface for Select Mercedes-Benz vehicles equipped with the NTG4.5 Infotainment System. It seamlessly integrates with the factory-installed system for activating both cameras. This Best in Class Interface offers an enhanced operational capability for switching between video sources via the factory Infotainment COMAND knob.

General Features:

Rear-view camera input with Dynamic Guidelines
On-screen Display options can be controlled by the factory COMAND Knob
Rear-view and Front-view camera inputs
Front camera input can also be used as an Auxiliary Video Input (Crux AUX-MB1 for Auxiliary Audio Input Option — Sold separately)
Automatic switching to rear-view camera input on engagement of reverse gear from all operation modes
Forced rear-view camera option
Manual return from rear-view and front camera (cancellation of automatic switching)
Compatible with all factory video accessories (e.g. rear-view camera, DVD-changer etc.)

Compatibility:

Mercedes-Benz
2013 – 2015 A-Class (W176)
2013 – 2016 B-Class (W246)
2013 -2014 CLA 250 (late 2014)
2012 – 2016 C-Class (W204)
2012 – 2016 C-Class (C204)
2012 – 2016 CLS (C218)
2012 – 2016 E-Class (W212)
2012 – 2016 E-Class (C207)

2013-2016 G Wagon (G463)

2013-2016 GL (X166)
2014 – 2016 GLA (X156)
2011 – 2016 GLK (W204)
2012 – 2016 ML (W166)
2012 – 2016 SLK (R172)
2013 – 2016 SL (R231)

COMAND Online NTG4.5 & Audio20 NTG4.5
6” / 7″ monitor and 4pin HSD LVDS connector
