Cerwin Vega Mobile H7SE10 Audio Control LC2iB and Amp KIT4 gauge package

Audio Control LC2i 2 Channel Line Out Converter Accubass and Subwoofer Control for amps to your factory system

The LC2i is a compact, two-channel processor with active input circuitry. It can accept speaker-level signals of up to 400 watts per channel from factory-installed source units or amplifiers and convert them to high-quality pre-amp signals that can be directed to after-market processors and amplifiers. Users can enjoy maximum sound quality while maintaining factory volume and steering wheel controls.

General Features:

• Two channels of active speaker level inputs - Accepts 400-watt signals per channel.
• AccuBASS processing for correction of bass roll-off
• Fixed and variable outputs with discrete level controls
• GTO - Signal sensing inputs
• The 12-Volt trigger that will turn on LC2i
• Dual amplifier
• 9.5-volt pre-amp outs
• Level matching controls
• 12 Volt trigger output
• Input for optional subwoofer level control: AudioControl ACR-1
• Dimensions: 6-3/8"W x 3-1/8"D x 1-1/2"H
• Authorized Internet Dealer
• 5 Year Manufacturer's Warranty (*when installed by an authorized Audio Control dealer)
• Maximum speaker level input: 400 watts per channel
• Maximum Preamp Output: 9.5Vrms / 13V peak
• Optional Dash Level Control Remote: +0dB / -19dB
• Frequency response: 10 Hz - 100,000 Hz; ±1dB
• Total harmonic distortion: 0.01%
• Signal to Noise ratio: >110dB
• Input Impedance: 20K ohms
• Output Impedance: 150 ohms
• Power draw: 150 mA
• Recommended fuse rating: 1 Amp
• Weight: 1 pound

What is in the LC2i box:

• Two-Channel line-output converter
• Instructions/Specs/Warranty (on packaging)
• Quality Control Certificate
• AudioControl LC2i owner's manual

Cerwin Vega H7SE10 1000W Max (200W RMS) HED Series Single 10" Sealed Shallow Mount Subwoofer Enclosure

General Features:

• 1000W Max (200W RMS) Single 10" Sealed Shallow Mount Subwoofer Enclosure
• Power Handling:
• Peak: 1000W Total
• RMS: 200W Total
• Final Impedance: 4 ohms
• Preloaded with single 10" HED Series Subwoofers
• Sealed enclosure with black carpet finish
• Enclosure Dimensions: 11.88" D x 18.5" W x 6" H
• Authorized Internet Dealer
• 1-year Manufacturer's Warranty

Subwoofer Features:

• Mounting Depth: 5
• Cutout Diameter: 9.17
• 2" 4 Layer voice coil
• 4 ohms audio control

Enclosure Features:

• 3/4" MDF Construction
• Black carpet finish
• Shallow mount for easy installation in tight spaces

Warning:
This product can expose you to, known to the State of California to cause cancer. For more information, go to P65Warnings.ca.
