The Yorkville Sound SA315S Synergy Array Series is a truly revolutionary active point source system with unmatched flexibility, power, and directivity control. The Synergy System offers users unrivaled simplicity without sacrificing sonic performance. The Synergy Array Series consists of the SA153 full-range powered cabinet, along with the SA315S powered subwoofer. This dynamic duo makes the ultimate point source speaker system scale-able for club gigs of all sizes, outdoor festivals, inclined seating venues, and arenas. Never before has a large point source system with this much output and sound quality been this easy to set up and use.



Product Specification:

Active or Passive: Active

Power Rating (Watts): 6500 Watts Program (13000 Watts Peak)

Measured Max SPL (C-Weighted, Max Hold): 130 dB Cont. 136 dB Peak

Frequency Response (Hz +/- 3dB): 31Hz-100Hz

Crossover Frequency (Hz): 100 Hz lowpass

Cabinet Configuration: Bass Reflex

Driver Configuration: 3x15" LF woofer

LF Driver(s): 15" Ceramic with 3" Voice Coil

LF Power Rating(Watts): 6500 Watts Program (13000 Watts Peak)

LF Impedance (Ohms): 2.7 ohm Load (3x 8 ohm)

LF Protection: Excursion, Voice Coil Thermal (RMS)

LF Power Amplifier (Watts): 6500 Watts Program (13000 Watts Peak)

LF Amplifier Type: Class D

Cooling Scheme: Convection

Power Cable: Removable Locking Powercon True Input and Loop Thru Output

Power Switch: Yes

Power Consumption (typ/max): 600 VA / 1200 VA

Inputs: 1 XLR with 2x XLR Parallel out, Impedance 35k ohms

Input Sensitivity (Vrms Sine): Line in 1.4 at center, 0.56 at max

Level Controls: Volume, -∞,0dB,8dB (Min, Top, Max)

EQ Controls: Thermal Limiter Advance for power consumption management

Limiter: Excursion, Thermal (RMS), Clipping

LED Indicators: Power, Excursion Limit, Thermal (RMS) Limit, Input Clip, Activity

Enclosure Materials: Multiply 15mm Birch Plywood

Standard Rigging Hardware: RAIL and LOCKBAR Rigging System (Top and Bottom)

Stacking Feature: Interlocking UHMW Feet (Top and Bottom)

Covering / Finish: Paint

Dimensions (DWH xbackW, inches): 24 x 21 x 51.5 x 12.25

Dimensions (DWH xbackW, cm): 60.9 x 53.3 x 130.8 x 31.1

Weight (lbs/kg): 236/107

Optional Synergy Series Accessories

Pick Up Bar (SAPICKUPBAR1): Single column cabinet hanging hardware (2xSA153 Plus 1xSA315S MAX)

Flying Bumper (SABUMPER1): 4 wide flying bumper (8xSA153 Plus 4xSA315S MAX)

SA153 Cabinet Cover (SA153COVER): Will cover 2 Cabinets (stacked)

SA315S Cabinet Cover (SA315SCOVER): Will cover 1 Cabinet

Cabinet Dolly (SADOLLY1): Holds 2 x SA153 stacked or 1 x SA315S
