Yorkville NX18SP NX 18” Powered Subwoofer

NX loudspeakers have a history of traditional analog design and a reputation for road-tested reliability. The new NX18SP is the first 18-inch subwoofer in the series two-decade tenure.

It was designed to be the perfect match for the latest generation of NX speakers. We suggest using one with a pair of NX8Ps, or two with a pair of NX12Ps for maximum sound reinforcement. As with all Yorkville Sound subwoofers, the NX18SP can be used to enhance any full-range system.

It features 2400 watts of peak output and three selectable voicing modes for rich, powerful bass in a compact, affordable enclosure.

NX speakers have been trusted on stages around the world for over 20 years, and the new NX18SP is ready to inspire a new generation of performers.

General Features:

• 2400 W Peak (1200 W Program)
• 18” Woofer with 4” Voice Coil
• 2x Combi-Jack (XLR / 1/4”) Inputs
• 2x XLR Link Outputs
• Punch, Smooth, and Deep Voicing Modes

Specifications

System Type	Powered
Power Rating	2400 watts peak (1200 watts program)
Max SPL	134 dB Peak (127 dB continuous)
Frequency Response (Hz +/- 3dB)	35 Hz - 100 Hz
Crossover Frequency	100 Hz
LF Driver(s)	18” with 4” Voice Coil
LF Amplifier Type	Class D
Cooling Scheme	Variable Speed Controlled Fan
In / Out Connections	2x XLR Link Outputs
Inputs	2x Combo-jack (XLR/1/4”)
Level Controls	Master - Sub Level
EQ Controls	Punch, Smooth, and Deep Voicing Modes
Wheels	Removeable
Bar Handles	2 (1x Each Side)
Pole Mount Adapter (1 3/8	1 (Top)
Enclosure Materials	15mm Birch
Covering / Finish	Textured Paint
Dimensions (DWH)	26.6" x 20.5" x 24.8" (67.6 cm x 52.1 cm x 63.0 cm) 31.6" x 20.5" x 24.8" (80.3 cm,x 52.1 cm x 63 cm) with Optional Wheels
Weight	104 lbs / 47.25 kg 110 lbs / 50 kg with Optional Wheels

**Specifications subject to change without notice
