Power Acoustik EW-104S 1200W Class S RMS Subwoofer
Power Acoustik EW-104S 1200W Class S RMS Subwoofer
The Power Acoustik EW-104S is a shallow-mount 10-inch subwoofer designed for tight-fit installations where standard-depth enclosures are not feasible. As part of the Edge Series, this model strikes a balance between power, precision, and space-conscious design, making it a solid option for sealed and compact vehicle subwoofer applications.
With 1200 watts peak and 600 watts RMS power handling, the EW-104S provides strong low-end output without demanding oversized enclosures or excessive power draw. The 4-ohm single voice coil configuration pairs easily with most mono or multi-channel car amplifiers.
Built with a polypropylene cone, stamped steel basket, and a 2-inch 4-layer copper voice coil, this subwoofer maintains cone rigidity and long-term thermal stability. A 60 oz magnet structure delivers steady motor force for accurate bass control, even in sealed boxes with a volume of less than 0.75 cubic feet.
General Features:
- 10″ shallow-mount subwoofer, ideal for under-seat or tight trunk installs
- 1200W max power, 600W RMS
- 4-ohm single voice coil, copper wound, 2″ diameter
- Mounting depth: ~2.5″ for space-limited enclosures
- Sensitivity: 81.3 dB, responsive to moderate power
- Frequency response: 25Hz – 250Hz
- Polypropylene cone with treated foam surround
- Sealed box optimization, recommended ~0.75 ft³ enclosure volume
|
Specifications
|
EW-104S |
|---|---|
|
Max Power Handling
|
1,200 Watts |
|
RMS Power Handling
|
600 Watts |
|
Efficiency (1w/1m)
|
81.30 |
|
Voice Coil Configuration
|
2.00″ 4Ω |
|
Motor Volume
|
60oz |
|
Mounting Depth
|
2.50″ |
|
Optimum Sealed Enclosure ft³
|
0.75
|
The EW-104S is tuned for those seeking deep bass in minimal space. Whether you’re configuring a stealth system, upgrading factory sub performance, or simply want strong lows without compromising trunk volume, this 10-inch shallow-mount subwoofer gets the job done.
It aligns with searches like “power acoustik 10 inch subwoofer”, “shallow mount subs 10”, “1200w 4-ohm car subwoofer”, and “edge series 10 inch car subwoofer”, all while keeping real specs front and center.
Warning:
This product can expose you to chemicals known to the State of California to cause cancer. For more information, go to P65Warnings.ca.
