On-Stage DB1000 Active DI Box

Our DB1000 Active DI Box converts any high-impedance 1/4" source to a low-impedance XLR signal ready to send via a long cable run to a mixer or PA system. Features include a -15 dB pad switch to prevent clipping, a throughput connector to pass unaltered signal to a stage amp, and a ground-lift switch to defeat ground-loop hum. Its heavy-duty metal enclosure protects the internal components and ensures reliable performance.

General Features:

• Converts a high-impedance (1/4") input to a balanced, low-impedance (XLR) output
• Output signal can be sent via a long cable to a mixer or PA system without frequency loss
• Active circuit features a high-quality transformer for low distortion and an isolated signal path
• -15 dB pad switch prevents clipping

Product Properties:

• Application
• Acoustic guitars, bass guitars, keyboards, and more

• Construction
• Metal w/ nylon bumpers

• Dimensions
• 6" x 3.5" x 1.5"

• Frequency Response
• 10Hz - 40kHz

• Ground lift
• Yes

• Input Resistance
• 220K Ohms

• Inputs
• 1/4"

• Output
• XLR

• Pad
• 15dB

• Power
• Phantom

• Product Type
• Direct Box

• Weight
• 0.70 lb
