Diamond Audio HX400.2 2-Channel 400W RMS Full Range Class D Amplifier

Audiophile-grade high tolerance components - 4-layer PCB board with balanced differential inputs - full-range digital class-d Ir chip sets - fine-tuned variable - crossover and phase control- top mounted controls for convenient amplifier adjustment turn to hex series amplifiers for superior sound quality and unparalleled power for the ultimate audiophile system set up. Composed of high-tolerance grade components and tuning adjustments to fit your listening desires, hex series amplifiers are the choice for those who expect the best!

General Features:

• Amplifier 2 Channel
• RMS Power(2Ω) 350 W X 2
• RMS Power (4Ω) 200 W X 2
• RMS Bridge (mono 2Ω) N/A
• RMS Bridge (mono 4Ω) 700 W X 1
• RMS Bridge (stereo 4Ω) N/A
• Topology Full-Range Class D
• Power Supply Full PWM
• Power Supply (Threshold) 10.0VDC – 17.0VDC
• Idle Current (0.7A)
• Distortion - THD (1KHz@4Ω) 0.06%
• Distortion - S/N Ratio (A weight @ 1W) -80dBA
• Distortion - S/N Ratio (A weight @ FP) -95dBA
• Input Sensitivity Low 200mV – 5.0V
• Input Sensitivity High N/A
• Input Impedance - Low Input Level 20 KΩ
• Input Impedance - High Input Level N/A
• Output Impedance 0.011Ω
• Damping Factor (50Hz@4Ω) >250
• Bandwidth (-3dB) 10Hz-35kHz
• Crossover (-12 dB/ Oct) Variable High-Pass 40Hz - 400Hz
• Crossover (-12 dB/ Oct) Variable Low-Pass 40Hz - 400Hz
• Crossover (-12 dB/ Oct) Variable Sub-Sonic N/A
• FUSE Ratings - ATC 25A X 2
• Dimension - Length x Width x Height - Inches(mm) 8.75″ x7.67″ x 2″ (222 x 195 x 51.5 mm)
